SQUARE FISH CAGES
The floating cage technology ensures the fish grow in a controlled environment with a monitored diet plan away from predators.
Square fish cages are suitable for inland waters, for example, lake, river, lagoon, dam and etc. Popular cage sizes are 4mx4m, 5mx5m, 6mx6m, 7mx7m and 8mx8m.
HDPE strong and robust structure
The floating cage technology ensures the fish grow in a controlled environment with a monitored diet plan away from predators.
Square fish cages are suitable for inland waters, for example, lake, river, lagoon, dam and etc. Popular cage sizes are 4mx4m, 5mx5m, 6mx6m, 7mx7m and 8mx8m.
HDPE strong and robust structure
- adaptable to local conditions
- double collar tube and handrail tube in HDPE 100 polyethylene plastic
- injection moulded brackets attached with stoppers and dowels around the full circumference
- evenly distributed pressure throughout the structure
- flexibility, strong, corrosion resistant
1)Anti-Windstorm capacity:Maximum grade 8
2) Ability of anti-wave:Maximum wave high of 3 meter in the water
3) Anti-flow capability:Maximum flow rate of 1.0m/s
1. Production to Delivery
2. On Site Inspection
3. Field Installation
4. Cage Farming
5. Fish Harvest
2) Ability of anti-wave:Maximum wave high of 3 meter in the water
3) Anti-flow capability:Maximum flow rate of 1.0m/s
| Structure | 4mx4m | 5mx5m | 6mx6m | 7mx7m | 8mx8m |
| Floating pipe | HDPEФ200mm | HDPEФ200mm | HDPEФ200mm | HDPEФ250mm | HDPEФ250mm |
| Handrail pipe | HDPEФ90mm | HDPEФ90mm | HDPEФ90mm | HDPEФ110mm | HDPEФ110mm |
| Stanchion pipe | HDPEФ90mm | HDPEФ90mm | HDPEФ90mm | HDPEФ125mm | HDPEФ125mm |
| Cage bracket | HDPE 200 | HDPE 200 | HDPE 200 | HDPE 250 | HDPE 250 |
| Fish net | 3m-4m | 3m-5m | 3m-6m | 4m-6m | 4m-6m |
